SQUARE EDGE FLAT
> Generally used for front mounted snow plow
> May also be used for appli- cation specific base edges on excavators & loaders
> Usually mae as bolt-on with holes in top or in the center (reversible)
> Holes may be countersunk, round or square
> Material is often high carbon steel
SINGLE BEVEL FLAT
> Commonly used as a weld on edge (welded to base of bucket)
> Can also be used as a base edge (made with or wihout holes to accomodate bolt- on edges, adapters or wear segments)
> Can be custom drilled or cut
> Can be either heat treated steel for wear or weldable steel for base edges.
DOUBLE BEVEL FLAT
> Generally meant as a Bolt- On wear edge for Loaders, Dozers, Graders, Scrapers, Backhoes & Excavators
> Commonly supplied with bolt holes center drilled (ex cept for Graders) to allow for the edge to be reversed after lead edge is worn
> Available without holes for custom weld-on applications
> Supplied in Heat-Treated or Thourgh-Hardened steel
HALF ARROW
> EIther Bolt-on or Weld-on
> Generally designed for Loader bucket applications
> Sometimes used as a replacement cutting edge for Excavators
> Sold in bulk lengths or cut into segments (custom holes and lengths available)
> Heat treated Boron steel
DOUBLE BEVEL CURVED
> Primarily used in Grader or Plow applications
> Generally supplied with square countersunk holes at the top of the blade
> Can be custom ordered with no holes or specialized holes
> Standard heat treated diamond steel (some smaller sizes made from high-carbon steel)
SERRATED
> Serrated (Ice Edges) can be made from Singel Bevel or Double Bevel Flat, or, Double Bevel Curved material
> Serrations can be cut into either side of the edge or both sides (reversible)
> Teeth are made with standard width and gap spacing (which depends on thickness and size of the edge)
> Custom serrations can be cut to specification
ROUTER BIT
> Designed to work on Scrapers
> They help move material into the center of the bowl and up the elevating conveyor
> Available in Standard & Heavy Duty for most major OEM Equipment
HOT CUPPED END BIT
> Made exclusively for Bull dozers
> Designed in a left & right hand configurations
> Dig deep into the surface material and help move it to the center of the blade to ensure even material flow
> Available in many
different thicknesses to suit your application (and most OEM Bulldozers)
