Hensley style direct replacement parts Parabolic series bucket teeth system backhoe dirt teeth X156 series Chinese Ground engaging Tool Suppliers

Short Description:

Direct replacement parts for Hensley parabolic bucket teeth syste.There are dirt bucket tooth dirt tooth X156,X156 flare bucket teeth,X156L long dirt bucket teeth,X156LP heavy duty dirt bucket teeth,X156T Tiger bucket teeth,X156WT twin tiger bucket teeth.


Product Detail

Product Tags

Direct replacement parts for Hensley parabolic bucket teeth syste.There are dirt bucket tooth dirt tooth X156,X156 flare bucket teeth,X156L long dirt bucket teeth,X156LP heavy duty dirt bucket teeth,X156T Tiger bucket teeth,X156WT twin tiger bucket teeth.Except X156series,there are other series for X160 series, X220 series,X290 series,X310 series X330 series,X370 series,X400 series,X410 series, X475 series,X485 series.there are many shapes,like dirt shape tip-standard,flare shape tip-wide,penetration tip,sharp tip,tiger tip,Rock chisel tip,twin tiger tip and so on. And pins for 156 series,P156.

Bucket tooth part no. bucket teeth profile pins
X156 Standard short teeth P156 roll pin
X156L standard long teeth P156 roll pin
X156H Heavy duty long  P156 roll pin
X156WT twin tiger teeth P156 roll pin
X156T tiger teeth P156 roll pin
X160 standard teeth P160 roll pin
X220 standard teeth P160 roll pin
X220T twin tiger teeth P160 roll pin
X220WT standard teeth P160 roll pin
X290 standard teeth P290 flex pin
X290T tiger teeth P290 flex pin
X290WT twin tiger teeth P290 flex pin
X290F Flare teeth P290 flex pin
X290RC Rock chisel teeth P290 flex pin
X310 standard teeth P310 flex pin
X310T Tiger teeth P310 flex pin
X310WT Twin tiger teeth P310 flex pin
X330 Standard teeth P330 flex pin
X330T Tiger teeth P330 flex pin
X330WT Twin tiger teeth P330 flex pin
X330F Flare teeth P330 flex pin
X330RC Rock chisel teeth P330 flex pin
X370 standard teeth P370 flex pin
X370T Tiger teeth P370 flex pin
X370WT twin tiger teeth P370 flex pin
X370RC Rock chisel teeth P370 flex pin
X400 standard teeth P400HD flex pin
X400T tiger teeth P400HD flex pin
X400WT twin tiger teeth P400HD flex pin
X410 standard teeth P410 flex pin
X410T tiger teeth P410 flex pin
X410WT twin tiger teeth P410 flex pin
X410RC Rock chisel teeth P410 flex pin
X450 standard teeth P450 flex pin
X450T tiger teeth P450 flex pin
X450WT twin tiger teeth P450 flex pin
X475 standard teeth P475HD
X475T tiger teeth P475HD
X475WT twin tiger teeth P475HD

Part Description

Mechanical Property

Teeth

Hardness HRC48-52, Impact strength(room temperature)≥18J

Adapter

Hardness HRC36-44, Impact strength(room temperature)≥20J

Grader Blades C80

Hardness HB280-320,Impact Strength≥7J(room temperature)

Cutting Edge 30MnB

Hardness HB440-480,Impact Strength≥25J(room temperature)

Cutting Edge 16Mn

Hardness HB330-370,Impact Strength≥40J(room temperature)



Advantage

1. Fast Delivery Time, lead time is around 35-40days.if stock availability, within one week.

2. Large Inventory, more than 5,000 items.

3. Strict Quality Management, testing hardness, impact strength, and test matchable one by one.

4. High impact strength and more wear material

5. Much more reasonable price

6. Professional, our factory has more than 20-year history on g.e.t field.

Quality Management

Impact testing

Impact Testing

spectrograph

Spectrograph

Hardness testing device

Tensile

tensile strength testing device

hardness

Stock Picture

stock-1
stock-3-4
stock-2

Shipment Picture

shipment-1
shipment-1
shipment-1
shipment-2

Production Process

1-Mould Design

1-Mould Design

2-Mould Processing

2-Mould Processing

3-Wax Model Making

3-Wax Model Making

4-Tree Assembly

4-Tree Assembly

5-Shell Building

5-Shell Building

6-Pouring

6-Pouring

7-Sprue Removal

7-Sprue Removal

8-Heat Treatment

8-Heat Treatment

9-Product Testing

9-Product Testing

10-Painting

10-Painting

11-Package

11-Package

About MINTER Profile

Ningbo Minter Machinery Co.,Ltd is a professional G.E.T located in China.Main products are Bucket teeth,adapter,cutting edge,bolt&nut,pin&retainer Chocky Bars and bucket wear protection. We provide direct replacement parts can be used for excavator,loader,bulldozers,scarifier,grader and snow plows,both construction sector and minning sector.
suit for most machinery brand like Caterpillar,Komatsu, Hitachi, Hyundai,Doosan,Volvo,JCB and some for Chinese machinery such as Sany XCMG,Liugong and so on.
There are complete & professional facilities in each production process.And we pay more attention to high standard for details from raw material selection to goods package and shipping. We are strict with delivery time.And our aime is simple,Committing to provide consistent high quality spare parts with excellent service for customers,to meet customers’ requirements and make effort to enlarge their market share and establish long-term cooperation with customers.
With strong technology term back-up and rich knowledge&experience on this field,we are able to provide R&D development to meet costomization requirement.
We focus on this industry. Join us to explore market together and pursuing what we want!

Q & A

1. What’s your delivery time?

Firstly, we will check our stock if availability, if no stocks, lead time is around 35-40days.

2.What’s your quality warranty ?

Promise no breakage happens.

Once breakage happens, we will have our technique team check and analyze. we will replace one by one for free if we should be responsible.

3.What kind of products you can offer ?

We are specialized in providing G.E.T parts like bucket teeth, adapter, cutting edge, side cutter, Protector, shank, ripper teeth, shank guard, fastners like bolt, nut,pin and retainers. Mainly for heavy machinery like excavators, loaders, dozers, motor graders and scrarifiers.

4.Are you a Manufacturer ?

Yes, we are a manufacturer located in Ningbo China. And we welcome to visit our factory.

5.Do you have Moq ?

No Moq. But if order quantity is less than 3tons, we have to surcharged for inland freight charge, port operation charge, file charge, export declaration charge etc..

6.What’s the biggest parts you can offer ?

We can provide PC1250, Caterpillar J800 spare parts,81 series as well. We are also striving into minning industry, expecting bigger parts can be casted later soon.
