Heavy machinery Locking system Pin Retainer Pin Plug for bucket tooth system for Caterpillar,Komatsu DRP pins, Hensley DRP pins,Befors, Libbherr,Hyundai,Doosan,Volvo,Hitachi,Kobelco,Sany

Short Description:

Ningbo Minter Machinery Co.,Ltd is specialized in providing pin retainer locking system with high quality,best cost-efficient and fast delivery time for bucket tooth which can be used for Caterpillar J series, Caterpillar K series, Komastu bucket tooth system. Conical series Super Conical series, Super V series, patent bucket teeth series,B-link bucket tooth series, Hensley Parabolic series,H&L bucket tooth system. Besides, for Volvo,Hitachi,Doosan,Hyundai Sany bucket tooth system.

The locking system pin& retainer is done with heat treatment, and hardness is controlled around HRC 38-42.Because there are large inventory of pin and retainer here.You could let us know your bucket tooth used or pin retainer part no. we will search for you.Plz kindly contact our sales person.


Product Detail

Product Tags

Ningbo Minter Machinery Co.,Ltd is specialized in providing pin retainer locking system with high quality,best cost-efficient and fast delivery time for bucket tooth which can be used for Caterpillar J series, Caterpillar K series, Komastu bucket tooth system. Conical series Super Conical series, series, patent bucket teeth series,B-link bucket tooth series, Hensley Parabolic series,H&L bucket tooth system. Besides, for Volvo,Hitachi,Doosan,Hyundai Sany bucket tooth system

The locking system pin& retainer is done with heat treatment, and hardness is controlled around HRC 38-42.Because there are large inventory of pin and retainer here.You could let us know your bucket tooth used or pin retainer part no. we will search for you.Plz kindly contact our sales person.

Pin part No. Measurement Retainer part No. Measurement Remark
8E6208 1U4208  9W7112 ¢11.1X62 8E6209  4T0001      9J4209 ¢19X6.3 J200
6Y3228     1324762 ¢14.3X67 8E6259  3G9609       1330699 ¢27X8.2 J225
8E6258 9J2258   8J4258 ¢14.3X80 8E6259  3G9609       8J5309   1330699 ¢27X8.2 J250
9J2308 1073308  8J5308 ¢14.3X92 8E6259  3G9609     8J5309  1330699 ¢27X8.2 J300
8E6358  9J2358  9W2678 1140358 ¢19X105 8E6359  3G9549      7J6845  1140359 ¢35X8.3 J350
7T3408    1167408 ¢22.2X118 8E8409                    1167409 ¢38.1X8.2 J400
6Y2527   1U1458 9W8296  4T1458    9W1458 ¢19X133 8E6359  1140359      3G9549  7J6845 ¢35X8.3 J450
8E0468    1040468 ¢23.8X133 8E8469                    1073469 ¢38.1X8 J460
6Y8558  1U1558    9W9026 1073378 ¢25.4X162 3G9559  8E5559     7J9559  1078559 ¢47.6X8 J550
6I6608     1139608 ¢30.1X194 6I6609                    1139609 ¢50.8X7.5 J600
4T4708 ¢32X195 4T4707   6Y1202              1134709 ¢64X9 J700
1020101    1341808 ¢35X240 1012874                  1341809 ¢68X9 J800
LC800 B ¢35X246
1368308/9W2668/9J6583 ¢19X89 1U2405 ¢38X9 R300
8E6358  9J2358  9W2678 1140358 ¢19X105 1140359 ¢35X8.3 R350
6Y3394 ¢25.4X127    8E4743 ¢47.6X8 R450
6Y3909   6Y1204 ¢31.8X142 4T4707   6Y1202 ¢64X9 R500
8E2229 ¢35X172 1012874                  1341809 ¢68.2X9.2 R550



Pin part no. Retainer part no. Komatsu
PC60 ¢17X68 PC60
20X-70-00100 ¢19.7X71.5 PC100
09244-02489 ¢24.7X88.5 PC120
09244-02496 ¢24.7X96 PC200
09244-02516 ¢24.7X117 PC300
09244-03036 ¢29.7X145 PC400
209-70-54240 ¢35.8X175 PC650
21N-72-14330 ¢39.8X176 PC1250
113-78-21170 ¢24.8X70 PC400 Sidebar protection
21N-939-3330 ¢29.8X96 PC700 sidebar protection
09244-02496 ¢24.7X96 D40-D53
175-78-21740   175-78-21810 ¢25X117 D60-D155
09244-02508 ¢24.7X113 D275
195-78-71360 ¢29.7X117 D375
09244-03036 ¢29.7X145 D455
198-78-21340PL   198-78-21410 ¢29.7X152 D475
426-847-1130 ¢29.7X136 WA500
427-70-13770 ¢37.3X150 WA600-WA700



Pin part No. Measurement Retainer part No. Measurement Remark ( Conical Tooth System)
18/20PN 55X13 18LK 35.5X16.5 18S
22PN 66X19 22LK 45X16 22S
25/30PN 74X20.4 25/30LK 37X21 25S 30S
35PN 87X23 35/40LK 47X23 35S
40PN 97X30 35/40LK 47X23 40S
45PN 100X34 45LK 57X24 45S

Part Description

Mechanical Property

Teeth

Hardness HRC48-52, Impact strength(room temperature)≥18J

Adapter

Hardness HRC36-44, Impact strength(room temperature)≥20J

Grader Blades C80

Hardness HB280-320,Impact Strength≥7J(room temperature)

Cutting Edge 30MnB

Hardness HB440-480,Impact Strength≥25J(room temperature)

Cutting Edge 16Mn

Hardness HB330-370,Impact Strength≥40J(room temperature)



Advantage

1. Fast Delivery Time, lead time is around 35-40days.if stock availability, within one week.

2. Large Inventory, more than 5,000 items.

3. Strict Quality Management, testing hardness, impact strength, and test matchable one by one.

4. High impact strength and more wear material

5. Much more reasonable price

6. Professional, our factory has more than 20-year history on g.e.t field.

Quality Management

Impact testing

Impact Testing

spectrograph

Spectrograph

Hardness testing device

Tensile

tensile strength testing device

hardness

Stock Picture

stock-1
stock-3-4
stock-2

Shipment Picture

shipment-1
shipment-1
shipment-1
shipment-2

Production Process

1-Mould Design

1-Mould Design

2-Mould Processing

2-Mould Processing

3-Wax Model Making

3-Wax Model Making

4-Tree Assembly

4-Tree Assembly

5-Shell Building

5-Shell Building

6-Pouring

6-Pouring

7-Sprue Removal

7-Sprue Removal

8-Heat Treatment

8-Heat Treatment

9-Product Testing

9-Product Testing

10-Painting

10-Painting

11-Package

11-Package

About MINTER Profile

Ningbo Minter Machinery Co.,Ltd is a professional G.E.T located in China.Main products are Bucket teeth,adapter,cutting edge,bolt&nut,pin&retainer Chocky Bars and bucket wear protection. We provide direct replacement parts can be used for excavator,loader,bulldozers,scarifier,grader and snow plows,both construction sector and minning sector.
suit for most machinery brand like Caterpillar,Komatsu, Hitachi, Hyundai,Doosan,Volvo,JCB and some for Chinese machinery such as Sany XCMG,Liugong and so on.
There are complete & professional facilities in each production process.And we pay more attention to high standard for details from raw material selection to goods package and shipping. We are strict with delivery time.And our aime is simple,Committing to provide consistent high quality spare parts with excellent service for customers,to meet customers’ requirements and make effort to enlarge their market share and establish long-term cooperation with customers.
With strong technology term back-up and rich knowledge&experience on this field,we are able to provide R&D development to meet costomization requirement.
We focus on this industry. Join us to explore market together and pursuing what we want!

Q & A

1. What’s your delivery time?

Firstly, we will check our stock if availability, if no stocks, lead time is around 35-40days.

2.What’s your quality warranty ?

Promise no breakage happens.

Once breakage happens, we will have our technique team check and analyze. we will replace one by one for free if we should be responsible.

3.What kind of products you can offer ?

We are specialized in providing G.E.T parts like bucket teeth, adapter, cutting edge, side cutter, Protector, shank, ripper teeth, shank guard, fastners like bolt, nut,pin and retainers. Mainly for heavy machinery like excavators, loaders, dozers, motor graders and scrarifiers.

4.Are you a Manufacturer ?

Yes, we are a manufacturer located in Ningbo China. And we welcome to visit our factory.

5.Do you have Moq ?

No Moq. But if order quantity is less than 3tons, we have to surcharged for inland freight charge, port operation charge, file charge, export declaration charge etc..

6.What’s the biggest parts you can offer ?

We can provide PC1250, Caterpillar J800 spare parts,81 series as well. We are also striving into minning industry, expecting bigger parts can be casted later soon.
