Komatsu style Caterpillar style Motor Grader Grader blades supplier Grade end-bit overlay replacement parts Chinese supplier

Short Description:

For grader end-bit grader overlay, bolt-on center edge, the material we used is 30MnB (Boron steel). Boron steel mechanical property is as below with heat treatment, hardness: HB460±20,Tensile: 1450Rm-N/mm²,Elongation: 11%, Impact test: 20J at 25℃ and 12J at -20℃。OEM is available to meet customers’requirements. We could provide blades parts for Caterpillar,Komatsu loaders excavators dozers and graders. Below is the parts what we can provide for Caterpillar and Komatsu grader scraper,please contact our sales for more detailed information.


Product Detail

Product Tags

For grader end-bit grader overlay, bolt-on center edge, the material we used is 30MnB (Boron steel). Boron steel mechanical property is as below with heat treatment, hardness: HB460±20,Tensile: 1450Rm-N/mm²,Elongation: 11%, Impact test: 20J at 25℃ and 12J at -20℃。OEM is available to meet customers’requirements. We could provide blades parts for Caterpillar,Komatsu loaders excavators dozers and graders. Below is the parts what we can provide for Caterpillar and Komatsu grader scraper,please contact our sales for more detailed information.

Caterpillar Motor grader Machinery mode Grader end-bit part no. Overlay part no.
112, 12, 12G 9W2945 (x2) 6D1904 (x2)
120, 130, 140 7D2052 (x2) 6D1948 (x2)
12G, 120G, 120H,
130G
8E5531 (x2) 9W1767 (x2)
135H, 140G, 140H,
143H
9W1768 (x2)
140H, 143H, 14H,
160H, 163H
8E5529 (x2) 6Y2805 (x2)
14 7D2083RH (x1),
7D2084LH (x1)
4D5757RH (x1) ,
4D5758LH (x1)
8E5529 (x2) 4D5757RH (x1) ,
4D5758LH (x1)
14G 9J4405RH (x1),
9J4406LH
7D9999 (x2)
9J4405RH (x1) ,
9J4406LH (x1)
6Y2805
16 9J4407RG (x1),
9J4408LH (x1)
7D5193 (x2)
16G 9D4880RH (x1),
9D4881LH (x1)
7D9999 (x2)
8E5530 (x2) 6Y2805 (x2)
16H 8E5530 (x2) N/A
212 9J4411 (x2) N/A
24H 109-3118 (x2) N/A



Komatsu Motor Grader Machinery Mode Grader end-bit part no. Overlay part no.
GD300A-1 237-870-1120 (X1),
237-870-1130 (X1)
232-70-12150 (X1),
232-70-12160 (X1)
GD313A, GD461A N/A 237-70-22150 (X2)
GD405A-1 N/A 232-70-52191 (X2)
GD500R-1 232-70-12130 (X2) 232-70-12150 (X1),
232-70-12160 (X1)
N/A 232-70-52191 (X2)
GD510R, GD511A, N/A 232-70-52190 (X2)
GD511R, GD513A, N/A 232-70-52190 (X2)
GD513R, GD521A N/A 232-70-52190 (X2)
GD521R, GD523A, N/A 232-70-52190 (X2)
GD523R, GD525A N/A 232-70-52190 (X2)
GD611A, GD611R, N/A 232-70-52190 (X2)
GD613A, GD613R, N/A 232-70-52190 (X2)
GD661A, GD663A N/A 232-70-52190 (X2)
GD600R, GD605A 234-70-12214 (X2) 234-70-12233 (X2)
GD605R, GD605R 232-70-52180 (X2) 232-70-52190 (X2)
GD655A, GD655R 232-70-52180 (X2) 232-70-52190 (X2)
GD600R, GD605A 232-70-52180 (X2) 232-70-52190 (X2)
GD605R, GD655A 232-70-52180 (X2) 232-70-52190 (X2)
GD655R, GD621 232-70-52180 (X2) 232-70-52190 (X2)
GD623, GD625 232-70-52180 (X2) 232-70-52190 (X2)
GD705R 234-70-12214 (X2) 234-70-12233 (X2)
GD705A, GD725A 234-70-32230 (X2) 234-70-32240 (X2)
GD825A 234-70-32230 (X2) 234-70-32240 (X2)

Part Description

Mechanical Property

Teeth

Hardness HRC48-52, Impact strength(room temperature)≥18J

Adapter

Hardness HRC36-44, Impact strength(room temperature)≥20J

Grader Blades C80

Hardness HB280-320,Impact Strength≥7J(room temperature)

Cutting Edge 30MnB

Hardness HB440-480,Impact Strength≥25J(room temperature)

Cutting Edge 16Mn

Hardness HB330-370,Impact Strength≥40J(room temperature)



Advantage

1. Fast Delivery Time, lead time is around 35-40days.if stock availability, within one week.

2. Large Inventory, more than 5,000 items.

3. Strict Quality Management, testing hardness, impact strength, and test matchable one by one.

4. High impact strength and more wear material

5. Much more reasonable price

6. Professional, our factory has more than 20-year history on g.e.t field.

Quality Management

Impact testing

Impact Testing

spectrograph

Spectrograph

Hardness testing device

Tensile

tensile strength testing device

hardness

Stock Picture

stock-1
stock-3-4
stock-2

Shipment Picture

shipment-1
shipment-1
shipment-1
shipment-2

Production Process

1-Mould Design

1-Mould Design

2-Mould Processing

2-Mould Processing

3-Wax Model Making

3-Wax Model Making

4-Tree Assembly

4-Tree Assembly

5-Shell Building

5-Shell Building

6-Pouring

6-Pouring

7-Sprue Removal

7-Sprue Removal

8-Heat Treatment

8-Heat Treatment

9-Product Testing

9-Product Testing

10-Painting

10-Painting

11-Package

11-Package

About MINTER Profile

Ningbo Minter Machinery Co.,Ltd is a professional G.E.T located in China.Main products are Bucket teeth,adapter,cutting edge,bolt&nut,pin&retainer Chocky Bars and bucket wear protection. We provide direct replacement parts can be used for excavator,loader,bulldozers,scarifier,grader and snow plows,both construction sector and minning sector.
suit for most machinery brand like Caterpillar,Komatsu, Hitachi, Hyundai,Doosan,Volvo,JCB and some for Chinese machinery such as Sany XCMG,Liugong and so on.
There are complete & professional facilities in each production process.And we pay more attention to high standard for details from raw material selection to goods package and shipping. We are strict with delivery time.And our aime is simple,Committing to provide consistent high quality spare parts with excellent service for customers,to meet customers’ requirements and make effort to enlarge their market share and establish long-term cooperation with customers.
With strong technology term back-up and rich knowledge&experience on this field,we are able to provide R&D development to meet costomization requirement.
We focus on this industry. Join us to explore market together and pursuing what we want!

Q & A

1. What’s your delivery time?

Firstly, we will check our stock if availability, if no stocks, lead time is around 35-40days.

2.What’s your quality warranty ?

Promise no breakage happens.

Once breakage happens, we will have our technique team check and analyze. we will replace one by one for free if we should be responsible.

3.What kind of products you can offer ?

We are specialized in providing G.E.T parts like bucket teeth, adapter, cutting edge, side cutter, Protector, shank, ripper teeth, shank guard, fastners like bolt, nut,pin and retainers. Mainly for heavy machinery like excavators, loaders, dozers, motor graders and scrarifiers.

4.Are you a Manufacturer ?

Yes, we are a manufacturer located in Ningbo China. And we welcome to visit our factory.

5.Do you have Moq ?

No Moq. But if order quantity is less than 3tons, we have to surcharged for inland freight charge, port operation charge, file charge, export declaration charge etc..

6.What’s the biggest parts you can offer ?

We can provide PC1250, Caterpillar J800 spare parts,81 series as well. We are also striving into minning industry, expecting bigger parts can be casted later soon.
